產品功能特點

設備特點Equipment features

• 烘箱長度縮短了一半，第二面涂布頭的漿料輸送管道距離同步縮短，整機長度縮短約40%；

The oven length is halved, and the distance of the slurry conveying pipeline for the second coating head is simultaneously shortened, reducing the overall machine length by approximately 40%;

• 整機能耗節約15-20%，效率提高了一倍；

Overall energy consumption is reduced by 15-20%, and efficiency is doubled;

• 放卷位于合漿側，收卷位于輥壓側，方便物料的轉運；

Unwinding is located on the slurry mixing side, and rewinding is located on the roller pressing side, facilitating material transfer;

• 第二面涂布后進烘箱前無長爬坡導輥機構，極片無打皺；

There is no long-slope guide roller mechanism before entering the oven after the second coating, preventing electrode wrinkling;

• 極片在烘箱內運行至一半長度時，折返處有閉環糾偏功能，極片在烘箱內無跑偏打皺；

When the electrode sheet reaches half its length within the oven, a closed-loop correction function at the folding point prevents deviation and wrinkling within the oven;

• 單節烘箱配置11根主被動過輥，消除過輥轉動阻力及整機過輥之間的轉速誤差；

Each oven section is equipped with 11 active and passive guide rollers, eliminating roller rotation resistance and speed errors between rollers throughout the machine;

• 烘箱內極片呈S型運行，干燥時極片無卷邊，極片運行穩定無抖動；

The electrode sheets inside the drying oven move in an S-shape, and there is no edge curling during drying; the electrode sheets move stably without shaking.
